Planar shadowless lights
CKVision’s cost-effective industrial lighting series provides systematic optical solutions, significantly improving detection efficiency and accuracy, with customizable options to meet precise size fits and complex application extensions.
Planar shadowless lights
This type of light offers diffuse light from the flat luminous surface, with advantages of simple and compact structure, easy to install, high uniformity and high angle light effect.
Features
Description
Diagram
Application
Examples
-
-
-
-
- High -density LED display, high brightness
- Compact structure design, saving installation space
- Optional diffuser plate, so that the light diffuses evenly
- Unique heat dissipation structure, improve the stability of light sources
- Ring-shaped light illuminates 360 degrees to highlight thethree-dimensional information of the product
-
-
-
• Hardware size measurement
• Robotic positioning
• Surface defect detection
• MARK point positioning
• PCB substrate detection
• Coding character recognition
• Unexplained surface characters
• Injury and dirt detection
• Microscopic lighting
• Wafer body test
• Electrical shell, part detection
• Fabric graphic inspection
| Model | Light Color | Power (W) | Outer / Length (mm) | Inner / Width (mm) | Height (mm) |
|---|---|---|---|---|---|
| CK-FNSL60-G | 2.2 | 60 | 18 | 15 | |
| CK-FNSL60-B | 2.2 | 60 | 18 | 15 | |
| CK-FNSL60-W | 2.2 | 60 | 18 | 15 | |
| CK-FNSL60-R | 1.3 | 60 | 18 | 15 | |
| CK-FNSL74-R | 1.8 | 74 | 20 | 18 | |
| CK-FNSL74-G | 2.6 | 74 | 20 | 18 | |
| CK-FNSL74-B | 2.6 | 74 | 20 | 18 | |
| CK-FNSL74-W | 2.6 | 74 | 20 | 18 | |
| CK-FNSL116-G | 4.3 | 116 | 44 | 17 | |
| CK-FNSL116-B | 4.3 | 116 | 44 | 17 |
