CK-RNE2-041MI-302GS
It transmits image data through a GigE data interface, integrates an I/O (GPIO) interface, and is equipped with a cable locking device. It supports optional PoE (Power over Ethernet) and can work stably in various harsh environments, making it a high-reliability industrial camera product.
Features
Dimensions
Specs
Downloads
- Trigger mode: Frame Start /Frame Burst Start
- Two exposure time modes: Standard / UltraShort
- Support Gamma, Digital Shift, Black Level
- Color models support Light source preset, Color Transformation Control and Saturation
- Mono models support Decimation, Binning
- Counter, LUTs and User Set Control
- Support Remove Parameter Limit to expand the range of exposure, gain, white balance, and so on
- 16K data storage area for saving algorithm coefficients and parameter configuratio
Sensor:
| Model | CK-RNE2-041MI-302GS | |
| Resolution | 720(H) × 540(V) | |
| Sensor | Sony IMX287 Global shutter CMOS | |
| Sensor Format | 1/2.9″ | |
| Pixel Size | 6.9μm × 6.9μm | |
| Frame Rate | 302.3 fps | |
| ADC | 12 bit | |
| Pixel Bit Depth | 8 bit, 12 bit | |
| Mono/Color | Mono | |
| Pixel Formats | Mono8 / Mono12 | |
| SNR | 43.1 dB | 43.03 dB |
| Exposure Time | UltraShort: 1μs ~ 100μs, Actual Steps: 1μs; Standard: 20μs ~ 1s, Actual Steps: 1 row period | |
| Gain | 0dB ~ 24dB; Default: 0dB, Steps: 0.1dB | |
| Binning | 1×1, 1×2, 2×1, 2×2 | |
| Decimation | FPGA: 1×1, 1×2, 2×1, 2×2 | |
| Synchronization | Hardware trigger, software trigger | |
| Acquisition Control | Single frame, Continuous, Software trigger, Hardware trigger | |
| Reverse X/Y | Reverse X/Y | |
| I/O Interface | 1 input and 1 output with opto-isolated, 1 programmable GPIO | |
| Data Interface | GigE | GigE PoE |
| Power Supply | 12VDC-10% ~ 24VDC+10% supplied via the camera’s Hirose connector
PoE is optiona (Power over Ethernet, IEEE802.3af compliant) |
|
| Typical Power | 2.30W @ 12VDC | 2.30W @ 12VDC
2.68W @ PoE |
| Operating Temp. | 0°C ~ +45°C | |
| Storage Temp. | -20°C ~ +70°C | |
| Operating Humidity | 10% ~ 80% | |
| Lens Mount | C / CS | |
| Dimensions | No PoE: 29(W) × 29(H) × 29(L) mm (without lens adapter or connectors)
PoE: 29(W) × 29(H) × 40.3(L) mm (without lens adapter or connectors) |
|
| Weight | No PoE: 65 g; PoE: 75 g | |
| Software | CKVisionBuilder or third-party software meeting with GigE Vision Protocol | |
| OS | 32bit / 64bit Windows, Linux, Mac OS | |
