CK-RNE2-502MU-79GS-HS
It features a compact design, built-in excellent Image Signal Processing (ISP) algorithms, and offers multiple acquisition methods. It transmits image data via a USB 3.0 data interface, supports I/O interfaces, and is equipped with a cable locking mechanism. Capable of operating stably in various harsh environments, it is a highly reliable industrial digital camera product.
Features
Dimensions
Specs
Downloads
- Trigger mode: Frame Start /Frame Burst Start
- Two exposure time modes: Standard exposure time mode / UltraShort exposure time mode
- Decimation, Binning, Digital Shift and Black Level
- Adjustable Gamma for optimizing the brightness of images
- Support Acquisition Burst Mode
- Color models support Light Source Preset, Color Transformation Control and Saturation
- Monochrome models support Noise Reduction and Sharpness
- Programmable LUTs and User Set Control
- Support Timer and Counter
- Support Remove Parameter Limit to expand the range of exposure, gain and so on
- 16KB data storage area for saving algorithm coefficients and parameter configuration
- 512KB ROM area for storing large amounts of data and files
Sensor:
| Model | CK-RNE2-502MU-79GS-HS |
| Resolution | 2448(H) × 2048(V) |
| Sensor | Sony IMX250 Global shutter CMOS |
| Sensor Format | 2/3″ |
| Pixel Size | 3.45μm × 3.45μm |
| Frame Rate | 79.1 fps
(Max. frame rate: 96.84fps @ Acquisition Burst Mode) |
| ADC | 10 bit |
| Pixel Bit Depth | 8 bit, 10 bit |
| Mono/Color | Mono |
| Pixel Formats | Mono8 / Mono10 |
| SNR | 40.67 dB |
| Exposure Time | UltraShort: 1μs~100μs, Actual Steps: 1 μs;
Standard: 20μs ~ 1s, Actual Steps: 1 row period |
| Gain | 0dB ~ 24dB; Default: 0dB, Steps: 0.1dB |
| Binning | 1×1, 1×2, 1×4, 2×1, 2×2, 2×4, 4×1, 4×2, 4×4 |
| Decimation | FPGA: 1×1, 1×2, 1×4, 2×1, 2×2, 2×4, 4×1, 4×2, 4×4
Sensor: 1×1, 2×2 |
| Synchronization | Hardware trigger , software trigger |
| Acquisition Mode | Single frame, Continuous, Software trigger, Hardware trigger , Acquisition
burst |
| Reverse X/Y | Reverse X/Y |
| I/O Interface | 1 input and 1 output with opto-isolated, 2 programmable GPIOs |
| Data Interface | USB3.0 |
| Power Supply | Power through USB3.0 interface |
| Typical Power | 2.44 W @ 5 VDC |
| Operating Temp. | 0° C ~ +45° C |
| Storage Temp. | -20 ° C~ +70° C |
| Operating Humidity | 10% ~ 80% |
| Lens Mount | C / CS |
| Dimensions | 29(W) × 29(H) × 45.5(L) mm |
| Weight | 65 g |
| Software | CKVisionBuilder or support USB3 Vision protocol software |
| OS | 32bit / 64bit Windows ，Linux ，Android ，ARMv7 ，ARMv8 |
