CK-RNE2-532CI-22GS(N)
It transmits image data via a GigE data interface, integrates an I/O (GPIO) interface, and is equipped with a cable locking mechanism. Capable of operating stably in various harsh environments, it is a high-reliability industrial camera product.
Features
Dimensions
Specs
Downloads
- Support Timed exposure mode and TriggerWidth exposure mode
- Support Decimation, Binning, Digital Shift, Black Level, Static Defect Pixel Correction
- Adjustable Gamma and Sharpness for optimizing the brightness and sharpness of images
- Color models support Light source preset, Color Transformation Control and Saturation
- Monochrome models support Noise Reduction
- Support Brust Acquisition and Level Controlled Exposure
- Timer, Counter, LUTs and User Set Control
Sensor:
| Model | CK-RNE2-532CI-22GS(N) |
| Resolution | 2592(H) × 2048(V) |
| Sensor | ON XGS5000 Global shutter CMOS |
| Sensor Format | 2/3″ |
| Pixel Size | 3.2μm × 3.2μm |
| Frame Rate | 22.17 fps (Max. frame rate: 42.17fps @ Acquisition Burst Mode) |
| ADC | 12 bit |
| Pixel Bit Depth | 8 bit, 12 bit |
| Mono/Color | Color |
| Pixel Formats | Bayer RG8 / Bayer RG12 |
| SNR | 39.76 dB |
| Exposure Time | UltraShort: 25μs ~ 99μs, Actual Steps: 1μs;
Standard: 100μs ~ 1s, Actual Steps: 1 row period |
| Gain | 0dB ~ 24dB; Default: 0dB, Steps: 0.1dB |
| Binning | 1×1, 1×2, 2×1, 2×2 |
| Decimation | Sensor: 1×1, 1×2, 2×1, 2×2 |
| Synchronization | Hardware trigger, software trigger |
| Acquisition Control | Single frame, Continuous, Software trigger, Hardware trigger, Acquisition burst |
| Reverse X/Y | Reverse X/Y |
| I/O Interface | 1 input and 1 output with opto-isolated, 1 programmable GPIO |
| Data Interface | GigE |
| Power Supply | 12VDC-10% ~ 24VDC+10% supplied via the camera’s 6-pin Hirose connector |
| Typical Power | 3.90W @ 12VDC |
| Operating Temp. | 0°C ~ +45°C |
| Storage Temp. | -20°C ~ +70°C |
| Operating Humidity | 10% ~ 80% |
| Lens Mount | C / CS |
| Dimensions | 29(W) × 29(H) × 29(L) mm (without lens adapter or connectors) |
| Weight | 68 g |
| Software | CKVisionBuilder or third-party software meeting with GigE Vision Protocol |
| OS | 32bit / 64bit Windows, Linux, Mac OS |
