CK-U500CI-24RS(N)
CK-U500CI-24RS(N) camera adopts AR0521 sensor to provide high-quality images. It uses GigE interface to transmit noncompressed images in real time, and its max. frame rate can reach 24 fps in full resolution.
Features
Dimensions
Specs
Downloads
- Adopts low power consumption design with stable performance.
- Supports auto and manual adjustment of gain, exposure time, etc.
- Supports hardware trigger, software trigger, free run, etc.
- Adopts GigE interface and max. transmission distance of 100 meters without relay.
- Compatible with GigE Vision V2.0 Protocol, GenlCam Standard, and third-party software based on the protocol and standard.
Sensor：
| Model | Product Model | CK-U500CI-24RS(N) |
| Type | 5MP Area Scan Camera, GigE, AR0521, Mono，No PoE | |
| Performance | Sensor type | CMOS, rolling shutter |
| Sensor model | AR0521 | |
| Pixel size | 2.2 μm × 2.2 μm | |
| Sensor size | 1/2.5″ | |
| Resolution | 2592 × 1944 | |
| Max. frame rate | 24 fps @ 2592 × 1944 Bayer GR 8 | |
| Dynamic range | 63 dB | |
| SNR | 37 dB | |
| Gain | 0 dB to 15 dB | |
| Exposure time | 21 μs to 1 sec | |
| Exposure mode | Off/Once/Continuous exposure mode | |
| Mono/color | Color | |
| Pixel format | Bayer GR 8/10/10Packed/12/12Packed | |
| Binning | Supports 1 × 1, 2 × 2 | |
| Decimation | Supports 1 × 1, 2 × 2 | |
| Reverse image | Supports horizontal and vertical reverse image output | |
| Electrical feature | Data interface | Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s) |
| Digital I/O | 6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2). | |
| Power supply | 9 VDC to 24 VDC, No PoE | |
| Power consumption | Typ. 1.81 W @ 12 VD | |
| Mechanical | Lens mount | C-mount |
| Dimension | 29 mm × 29 mm × 42 mm (1.1″ × 1.1″ × 1.7″) | |
| Weight | Approx. 100 g (0.2 lb.) | |
| Ingress protection | IP30 (under proper lens installation and wiring) | |
| Temperature | Working temperature: 0 °C to 50 °C (32 °F to 122 °F) Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F) | |
| Humidity | 20% RH to 80% RH (no condensation) | |
| General | Client software | CKVisionBuilder or third-party software meeting with GigE Vision Protocol |
| Operating system | 32/64-bit Windows XP/7/10/11, 32/64-bit Linux, and 64-bit MacOS | |
| Compatibility | GigE Vision V2.0, GenICam |
